CC wheel has a universal Spoke pattern in the hubs, ie all hubs within the same size group has the same spokes regardless of make, model and year. (Except YZ 65)
| KX, SX, TC och RM 65 cc | Placement | Spokes | Art. Nr. |
| Rear 12 inch 1,40/1,60 | Spoke Set | 28 spokes | 50-0189 |
| Rear 12 inch 1,40/1,60 | 1 kind of spoke | 3,6x125 mm | 50-0189-1 |
| Front 14 inch 1,40 | Spoke Set | 28 spokes | 50-0190 |
| Front 14 inch 1,40 | 1 kind of spoke | 3,6x147 mm | 50-0190-1 |
| YZ 65 cc | Placement | Spokes | Art. Nr. |
| Rear 12 inch 1,40/1,60 | Spoke Set | 32 spokes | 50-0177 |
| Rear 12 inch 1,40/1,60 | 1 kind of spoke | 3,6x125 mm | 50-0177-1 |
| Front 14 inch 1,40/1,60 | Spoke Set | 32 spokes | 50-0176 |
| Front 14 inch 1,40/1,60 | 1 kind of spoke | 3,6x145 mm | 50-0176-1 |
| 85 cc, CRF 150 and KTM Freeride | Plcement | Spokes | Art. Nr. |
| Front 17 inch 1,40/1,60 | Spoke Set | 32 spokes | 50-0191 |
| Front 17 inch 1,40/1,60 | 1 kind of spoke | 4x184 mm | 50-0191-1 |
| Front 17 inch 3,50 | Spoke Set | 32 spokes | 50-0192 |
| Front 17 inch 3,50 | 1 kind of spoke | 4x180 mm | 50-0192-1 |
| Front 19 inch 1,40/1,60 | Spoke Set | 32 spokes | 50-0193 |
| Front 19 inch 1,40/1,60 | 1 kind of spoke | 4x208 mm | 50-0193-1 |
| Front 21 inch 1,60/1,85 | Spoke Set | 32 spokes | 50-0184 |
| Front 21 inch 1,60/1,85 | 1 kind of spoke | 3,6x232 mm | 50-0184-1 |
| Rear 14 inch 1,60 | Spoke Set | 32 spokes | 50-0194 |
| Rear 14 inch 1,60 | 1 kind of spoke | 4x151 mm | 50-0194-1 |
| Rear 16 inch 1,85 | Spoke Set | 32 spokes | 50-0195 |
| Rear 16 inch 1,85 | 1 kind of spoke | 4x173 mm | 50-0195-1 |
| Rear 17 inch 3,50 | Spoke Set | 32 spokes | 50-0180 |
| Rear 17 inch 3,50 | Left side 16/32 | 4x179 mm | 50-0180-1 |
| Rear 17 inch 3,50 | Right side 16/32 | 4x185 mm | 50-0180-2 |
| Rear 18 inch 1,85/2,15 | Spoke Set | 32 stycken | 50-0183 |
| Rear 18 inch 1,85/2,15 | 1 kind of spoke | 3,6x196 mm | 50-0183-1 |
| Big motorcycles 125 cc and up | Placement | Spokes | Art. Nr. |
| Front 16,5 inch 3,50 | Spoke Set | 36 spokes | 50-0188 |
| Front 16,5 inch 3,50 | 1 kind of spoke | 4x170 mm | 50-0188-1 |
| Front 17 inch 3,50 | Spoke Set | 36 spokes | 50-0204 |
| Front 17 inch 3,50 | 1 kind of spoke | 4x176 mm | 50-0204-1 |
| Front 19 inch 1,85/2,15/2,50 | Spoke Set | 36 spokes | 50-0200 |
| Front 19 inch 1,85/2,15/2,50 | 1 kind of spoke | 4x205 mm | 50-0200-1 |
| Front 19 inch 2,50 MT Profil | Spoke Set | 36 spokes | 50-0201 |
| Front 19 inch 2,50 MT Prifil | 1 kind of spoke | 4x202 mm | 50-0201-1 |
| Front 21 inch 1,60/1,85 | Spoke Set | 36 spokes | 50-0203 |
| Front 21 inch 1,60/1,85 | 1 kind of spoke | 4x232 mm | 50-0203-1 |
| Front 21 inch 2,15 | Spoke Set | 36 spokes | 50-0202 |
| Front 21 inch 2,15 | 1 skind of spoke | 4x230 mm | 50-0202-1 |
| Rear 17 inch 4,25 | Spoke Set | 36 spokes | 50-0182 |
| Rear 17 inch 4,25 | 1 kind of spoke | 4x172 mm | 50-0182-1 |
| Rear 17 inch 5,00/5,50 | Spoke Set | 36 spokes | 50-0187 |
| Rear 17 inch 5,00/5,50 | Right side 18/36 | 4x168 mm | 50-0187-1 |
| Rear 17 inch 5,00/5,50 | Left side 18/36 | 4x173 mm | 50-0187-2 |
| Rear 18 inch 1,85/2,15/2,50 | Spoke Set | 36 spokes | 50-0198 |
| Rear 18 inch 1,85/2,15/2,50 | 1 skind of spoke | 4x188 mm | 50-0198-1 |
| Rear 18 inch 2,50 MT Profil | Spoke Set | 36 spokes | 50-0185 |
| Rear 18 inch 2,50 MT Profil | 1 kind of spoke | 4x184 mm | 50-0185-1 |
| Rear 19 inch 1,85/2,15/2,50 | Spoke Set | 36 spokes | 50-0199 |
| Rear 19 inch 1,85/2,15/2,50 | 1 kind of spoke | 4x201 mm | 50-0199-1 |
| Rear 19 inch 2,50 MT Profil | Spoke Set | 36 spokes | 50-0186 |
| Rear 19 inch 2,50 MT Profil | 1 kind of spoke | 4x200 mm | 50-0186-1 |
CC Products stainless spoke with nipple 4x191 mm Fits the following CC wheels: All CC Products 18x1.85, 18x2.15 and 18x2.50 wheels for all big motorcycles with WM profile, see picture. If you have 18x2.50 with WM Profile you should have spoke 50-0185-1. There is only one kind of spokes in these wheels. Spoke size: 36 spokes of 4x191 mm. Loxeal 10 ml. thread lock can be purchased separately on article number 52-2418. Nipple size: 7,6x20 mm. (8G/300) If the spoke nipple holes are smaller or larger you may need to change spoke nipples to another size.
50 SEK per Each
CC Products stainless spoke with nipple 4x170 mm. Fits the following CC wheels: All CC Products wheels for all big motorcycles. For 17x4,25 and 17x4,50 rear wheel. There are only one kind of spokes in these wheels. Spoke size: 36 spokes of 4x170 mm. Loxeal 10 ml. thread lock can be purchased separately on article number 52-2418. Nipple size: 7,6x20 mm (8G/300) If the spoke nipple holes are smaller or larger you may need to change spoke nipples to another size.
50 SEK per Each
CC Products stainless spoke with nipple 4x184 mm. Fits the following CC wheels: All CC Products wheels for all big motorcycles with 18x2,50 front rims with MT profile, see picture. If you have 18x1.85, 18x2.15 or 18x2.50 with WM Profile you should have spoke 50-0187-1. There is only one kind of spokes in these wheels. Spoke size: 36 spokes of 4x184 mm. Loxeal 10 ml. thread lock can be purchased separately on article number 52-2418. Nipple size: 7,6x20 mm. (8G/300) If the spoke nipple holes are smaller or larger you may need to change spoke nipples…
50 SEK per Each
CC Products stainless spoke with nipple 4x202 mm. Fits the following CC wheels: All CC Products 19x2.50 wheels for all big motorcycles (125 cc->) with MT profile, see picture. If you have 19x2.50 with WM Profile you should have spoke 50-0185-1. There is only one kind of spokes in these wheels. Spoke size: 36 spokes of 4x202 mm. Loxeal 10 ml. thread lock can be purchased separately on article number 52-2418. Nipple size: 7,6x20 mm. (8G/300) If the spoke nipple holes are smaller or larger you may need to change spoke nipples to another size.
50 SEK per Each
CC Products stainless spoke with nipple 4x168 mm. Fits the following CC wheels: All CC Products wheels for all big motorcycles For: 17x5,00 and 17x5,50 rear wheel. There are 2 kinds of spokes and 36 spokes in total in these wheels. Spoke size: 18 spokes of 4x168 mm. Disc side. Loxeal 10 ml. thread lock can be purchased separately on article number 52-2418. Nipple size: 7,6x20 mm. (8G/300) If the spoke nipple holes are smaller or larger you may need to change spoke nipples to another size.
50 SEK per Each
CC Products stainless spoke with nipple 4x175 mm. Fits the following CC wheels: All CC Products wheels for all big motorcycles For: 17x5,00 and 17x5,50 rear wheel. There are 2 kinds of spokes and 36 spokes in total in these wheels. Spoke size: 18 spokes of 4x175 mm. Sprocket side. Loxeal 10 ml. thread lock can be purchased separately on article number 52-2418. Nipple size: 7,6x20 mm. (8G/300) If the spoke nipple holes are smaller or larger you may need to change spoke nipples to another size.
50 SEK per Each
CC Products stainless spoke with nipple 4x170 mm Fits the following CC wheels: All CC Products wheels for all big motorcycles with 16,5x3,50 front rims. There is only one kind of spokes in these wheels. Spoke size: 36 spokes of 4x170 mm. Loxeal 10 ml. thread lock can be purchased separately on article number 52-2418. Nipple size: 7,6x20 mm (8G/300). If the spoke nipple holes are smaller or larger you may need to change spoke nipples to another size.
50 SEK per Each
CC Products stainless spoke with nipple 125 mm. Fits the following CC wheels: CC rear wheels 65 cc 12x1,40 and 12x1,60 rims. KX 65 RM 65 SX 65 TC 65 NOTE! Do NOT fit YZ 65! There are only 1 kind of spoke and 28 spokes in total in these wheels. Spoke size: 28 spokes of 125 mm. This spoke is available in both 3,2 mm and 3,6 mm. Loxeal 10 ml. thread lock can be purchased separately on article number 52-2418. Nipple size: 7,0x20 mm. (275) If the spoke nipple holes are smaller or…
50 SEK per Each
CC Products stainless spoke with nipple Fits the following CC wheels: For CC Products front wheels for all 85 cc and CRF 150 with 17-inch front rims. There is only one kind of spokes in these wheels. Spoke size: 36 spokes of 4x184 mm. Loxeal 10 ml. thread lock can be purchased separately on article number 52-2418. Nipple size: 7,6x20 mm. (8G/300) If the spoke nipple holes are smaller or larger you may need to change spoke nipples to another size.
50 SEK per Each
CC Products stainless spoke with nipple 4x208 mm. Fits the following CC wheels: For CC Products front wheels 19-inch for all 85 cc and CRF 150. There is only one kind of spokes in this wheel. Spoke size: 32 spokes of 4x208 mm. Loxeal 10 ml. thread lock can be purchased separately on article number 52-2418. Nipple size: 7,6x20 mm. (8G/300) If the spoke nipple holes are smaller or larger you may need to change spoke nipples to another size.
50 SEK per Each
CC Products stainless spoke with nipple Fits the following CC wheels: For CC Products rear wheels for all 85 cc and CRF 150 with 14-inch rear rims. There is only one kind of spokes in these wheels. Spoke size: 36 spokes of 4x151 mm. Loxeal 10 ml. thread lock can be purchased separately on article number 52-2418. Nipple size: 7,6x20 mm. (8G/300) If the spoke nipple holes are smaller or larger you may need to change spoke nipples to another size.
50 SEK per Each
CC Products stainless spoke with nipple 4x173 mm. Fits the following CC wheels: For CC Products 16-inch rear wheels for all 85 cc and CRF 150. There is only one kind of spokes in this wheel. Spoke size: 32 spokes of 4x173 mm. Loxeal 10 ml. thread lock can be purchased separately on article number 52-2418. Nipple size: 7,6x20 mm. (8G/300) If the spoke nipple holes are smaller or larger you may need to change spoke nipples to another size.
50 SEK per Each
CC Products stainless spoke with nipple 4x188 mm. Fits the following CC wheels: All CC Products 18-inch rear wheels for big motorcycles (125 cc->) If you have a 18x2,50 rim with MT profile you should use spoke 50-0185-1. There is only one kind of spokes in these wheels. Spoke size: 36 spokes of 4x188 mm. Loxeal 10 ml. thread lock can be purchased separately on article number 52-2418. Nipple size: 7,6x20 mm. (8G/300) If the spoke nipple holes are smaller or larger you may need to change spoke nipples to another size.
50 SEK per Each
CC Products stainless spoke with nipple Fits the following CC wheels: All CC Products 19x1.85, 19x2.15 or 19x2.50 rear wheel for big motorcycles (125 cc->) with WM profile. If you have a 19x2,50 rim with MT profile you should use spoke 50-0186-1. There is only one kind of spokes in these wheels. Spoke size: 36 spokes of 4x201 mm. Loxeal 10 ml. thread lock can be purchased separately on article number 52-2418. Nipple size: 7,6x20 mm. (8G/300) If the spoke nipple holes are smaller or larger you may need to change spoke nipples to another size.
50 SEK per Each
CC Products stainless spoke with nipple 4x205 mm Fits the following CC wheels: All CC Products 19-inch front wheels for all big motorcycles (125 cc->) There is only one kind of spoke in these wheels. Spoke size: 36 spokes of 4x205 mm. Loxeal 10 ml. thread lock can be purchased separately on article number 52-2418. Nipple size: 7,6x20 mm. (8G/300) If the spoke nipple holes are smaller or larger you may need to change spoke nipples to another size.
50 SEK per Each
CC Products stainless spoke with nipple 4x202 mm Fits the following CC wheels: All CC Products wheels for all big motorcycles with 19x2,50 front rim with MT profile. See picture. If you want spokes for a 19x2,50 rim with WM profile you should use spoke 50-0200-1. There is only one kind of spokes in these wheels. Spoke size: 36 spokes of 4x202 mm. Loxeal 10 ml. thread lock can be purchased separately on article number 52-2418. Nipple size: 7,6x20 mm. (8G/300) If the spoke nipple holes are smaller or larger you may need to change spoke…
50 SEK per Each
CC Products stainless spoke with nipple 4x205 mm Fits the following CC wheels: All CC front wheels for big motorcycles (125 cc ->) with 19x3,00 rims. There is only one kind of spoke in this wheel. Spoke size: 36 spokes of 4x199 mm. Loxeal 10 ml. thread lock can be purchased separately on article number 52-2418. Nipple size: 7,6x20 mm. (8G/300) If the spoke nipple holes are smaller or larger you may need to change spoke nipples to another size. One individual spoke and nipple, 4x199 mm, have article number 50-0202-1
50 SEK per Each
CC Products stainless spoke with nipple 4x232 mm. Fits the following CC wheels: All CC Products wheels for all big motorcycles with 21x1,60 and 21x1,85 front rims. There is only one kind of spokes in these wheels. Spoke size: 36 spokes of 4x232 mm. Loxeal 10 ml. thread lock can be purchased separately on article number 52-2418. Nipple size: 7,6x20 mm. (8G/300) If the spoke nipple holes are smaller or larger you may need to change spoke nipples to another size.
50 SEK per Each
CC Products stainless spoke with nipple 4x176 mm. Fits the following CC wheels: All CC Productsfront wheels for all big motorcycles (125 cc->) with 17x3,50 rear rims with standard lacing. (Not X-lace) There is only one kind of spokes in these wheels. Spoke size: 36 spokes of 4x176 mm. Loxeal 10 ml. thread lock can be purchased separately on article number 52-2418. Nipple size: 7,6x20. If the spoke nipple holes are smaller or larger you may need to change spoke nipples to another size.
50 SEK per Each
CC Products stainless spoke with nipple 4x178 mm. Fits the following CC wheels: All CC Products Front wheels for all big motorcycles (125 cc->) with 17x3,50 rims with X-lacing. X-lace gives more room for the brake caliper and better stability in curves. There is only one kind of spokes in these wheels. Spoke size: 36 spokes of 4x178 mm. Loxeal 10 ml. thread lock can be purchased separately on article number 52-2418. Nipple size: 7,6x20 mm (8G/300). If the spoke nipple holes are smaller or larger you may need to change spoke nipples to another size.
50 SEK per Each
CC Products stainless spoke with nipple 4x175 mm Fits the CC wheels: All CC Products wheels for all big motorcycles with 16,5x3,50 front rims with X-Lace. There is only one kind of spokes in these wheels. Spoke size: 36 spokes of 4x175 mm. Loxeal 10 ml. thread lock can be purchased separately on article number 52-2418. Nipple size: 7,6x20 mm (8G/300). If the spoke nipple holes are smaller or larger you may need to change spoke nipples to another size.
50 SEK per Each
